XLR Balanced Audio over Fiber Optic Extender A Pair- Singlemode up 20Km LC SFP Include Uncompressed Broadcast grade Professional Crystal Clear Sound
Feature: 【Function】The xlr fiber audio extender can extend 1-16 channels of Balanced xlr broadcast high grade Audio over over fiber optic cable to...
- $299.00
$348.00- $299.00
- Unit price
- per
Please hurry! Only 100 left in stock
Limited-Time Offers, End in:
151D
8H
23M
0S
10 customers are viewing this product
Couldn't load pickup availability
Free Shipping
Free standard shipping on orders over $99
Estimated to be delivered on 12/01/2022 - 15/10/2022.
Free Returns
Learn More.
Built And Shipped Within 5 - 7 Bussiness Days
Feature:
【Function】The xlr fiber audio extender can extend 1-16 channels of Balanced xlr broadcast high grade Audio over over fiber optic cable to far end. It allows 1-16 XLR audio device synchronous transmission, No debugging required. 1-16 XLR Audio signal is transmitted from T (TX) in the direction of R (RX)
【Long Transmission range】It can work on both single-mode and multi-mode fiber cable. Long transmission distance: Single mode up to 12.4 miles (20Km), ,multi-mode single fiber up to 1640FT(500meters)
【Crystal clear sound, No Loss, No Delay】 Professional quality ,Pure and Clean fiber optic audio signal transmission
【Wide Applications】Typically used in applications for Staging, Theaters, Stadiums, Parks, Broadcast, studio audio and professional AV applications, etc., and are available for stand-alone and desktop type, or wall mounted, installations
【Plug and Play】No need to set up ,Plug and play. Simply plug in an Optical LC port and XLR audio connectors at TX and RX sides, it will have crystal clear sound instantly
4 Channel (Unidirectional ,one way)
2 Channel (Bidirectional ,two way)
Optical Port:
Optical connector: LC
Wavelength: 1310nm/1550nm.
Transmitting optical power: more than -7db.
Receiving sensitivity: more than -24db
Fiber: single fiber multimode (MM) or single mode (SM).
Transmission range: 0-20km for singlemode fiber, 0-500m for multimode fiber
Optical fiber type: universal 9/125u single mode, 50/125u or 62.5/125u multimode.
XLR Audio Ports:
Number of Channels: 1/2/4/8/16 is opitonal, bidirectional 1/2/4/8 is optional
Input Connector: XLR (Female).
Output Connector: XLR (Male).
Pin wiring diagram : "1" Shield, "2" MIC AUDIO (+), "3" MIC AUDIO (-)
Input / Output Impedance: 600 Ohm.
Max input/output voltage: 4.0Vp-p.
Signal level: 0.5-4Vp-p.
Sampling frequency: 192 KHz.
Audio A/D sampling: 24 Bit
SNR: 100dB.
Audio interface level III lightning protection, reaching IEC61000-4-5 (8/20 μ s) Differential mode: 6KV.
General Spec:
Power Consumption: ≤8W.
Working temperature: -20°C ~ +70°C.
Relative Humidity: 0% ~ 95% (non-condensing).
MTBF: >100,000 hours.
Installation: stand-alone.
Support wide range working Voltage: AC100-240V 50/60Hz, DC12V
Power plug：US/EU/UK/AU standard is optional.
Dimension: 167mm(L)×114mm(W)×45mm(H).
Package include:
1x Balanced XLR Audio Fiber Transmitter
1x Balanced XLR Audio Fiber Receiver
2x Power supply adapter (US/EU/UK/AU standard is optional)
1x FREE 3M LC-LC Fiber patch cord
1x Manual.
